SojaPress 300 – Soy Extrusion and Oil Pressing Line

SojaPress 300 – Soy Extrusion and Oil Pressing Line

In Stock
Rating:

In Stock 211,375.50
171,850.00zł

Incl Tax: 211,375.50zł


  • Product Code: SojaPress - 300

Warranty and service
About Us
Delivery and Payment
Contact

Main characteristics All specifications
Product type: Mini Oil Pressing Line
Usage: For pressing oil
Type of drive: Electric
Production capacity: up to 300 kg/h
Voltage: 380 - 400 V

Description

The SojaPress 300 line, produced by Technomaszbud, is designed for the production of extruded soy and oil from the pulp formed after extrusion. The line’s capacity is up to 300 kg of processed raw material per hour, and the only input material is soybeans.

The line effectively solves the problem of cleaning soybeans from impurities, calibrating them, crushing them, and processing them into extruded feed or producing oil from the soybean cake.

Technological Process:

  1. Soybeans are fed into the calibrator via a flexible screw conveyor, where they undergo initial cleaning from impurities.
  2. Aspiration removes excess dust.
  3. Calibrated seeds are transported to the huller, where the seeds are dehulled.
  4. The cleaned soybean seeds, after hulling, are fed into the extruder, where they undergo thermal treatment using the extrusion method.
  5. The extruded soybean meal is transferred to the press, where the oil is extracted.
  6. After pressing, the soybean cakes are transported to the cooler and then prepared for packaging.

Line Components:

  1. 6m Flexible Conveyor
  2. KZ-500 Seed Calibrator
  3. PT-250 Belt Conveyor
  4. Dust Collection System
  5. Seed Huller
  6. PK-2 Calibrator Conveyor
  7. EGK-350 Soy Extruder
  8. Screw Feeder
  9. WT-150 DOUBLE Oil Press
  10. 40L Solid Particle Separator with Level Sensor
  11. PT-Z Belt Conveyor with 6 Cooling Fans
  12. Oil Filter with Pump
  13. Control Panel

Specification

Key features
Product type
Mini Oil Pressing Line
Usage
For pressing oil
Type of drive
Electric
Production capacity
up to 300 kg/h
Voltage
380 - 400 V
Additional features
Warranty
12 months
Key features
Product type
Mini Oil Pressing Line
Usage
For pressing oil
Type of drive
Electric
Production capacity
up to 300 kg/h
Voltage
380 - 400 V
Additional features
Warranty
12 months
