Wood shredder/ Chipper CR-500 with combustion engine
In Stock
- Product Code: CR-500 SP
Main characteristics
All specifications
Length:
1621 mm
Width:
1117 mm
Height:
1715 mm
Weight:
300 kg
Product type:
Wood shredder / Chipper
Description
CR-500 is a new product from the manufacturer TechnoMaszBud.
The production line, equipped with a CR-500 chipper working with a hammer mill, is becoming more efficient than ever. This device makes
the pellet production process efficient, saving time and costs, while remaining environmentally friendly. The CR-500 chipper, hammer mill
mill, aerodynamic sawdust dryer and production line, the heart of which is a pellet mill, is a perfect solution for anyone involved in pellet
production.
The CR-500 wood chipper is a disc-type shredding device used for grinding/grinding/crushing post-production waste from the sawmill,
carpentry and furniture industries, namely: tree branches, wooden waste, boards, edgings, sawing blades, chipboards, MDF boards with
maximum dimensions: width 210 mm x height 160 mm.
CR-500 allows you to obtain fuel wood chips or technological chips for further processing in production lines into fuel pellets.
The big advantage of the CR-500 wood chipper is the large size of the loading opening, which allows you to crush large pieces of
incoming material.
The chipper is equipped with two rollers feeding the raw material to the working part, i.e. a rotating disc with mounted blades.
The hydraulic pump driving the rollers allows them to be stopped or reversed if necessary. The knives (blades) of the disc are made of
9ХС tool steel (equivalent to 9ChS/9KhS).
Basic technical parameters:
- productivity up to 10 m³/h of finished chips;
- combustion engine power 30 HP;
- maximum dimensions of the processed raw material (width x height): 210 mm x 160 mm;
- it is operated by only 1 person;
- the final fraction of chips is in the range of 5–45 mm;
- the blades of the disc are made of extremely durable 9ХС steel (equivalent to 9ChS/9KhS).
Additionally, installed elements, such as a speed regulator of the raw material intake rollers, a hydraulic system oil filter and a pressure
gauge for monitoring the hydraulic system, ensure comfortable and effective operation which makes the CR-500 an irreplaceable tool in
the wood industry.
The CR-500 wood chipper/shredder is a device that can be used as a separate shredder for the production of fuel chips or as a
component in a production line for eco-fuel, i.e. pellets.
Specification
Dimensions
Length
1621 mm
Width
1117 mm
Height
1715 mm
Weight
300 kg
Key features
Product type
Wood shredder / Chipper
Usage
for shredding tree branches, wood waste, sawing blades with a maximum diameter of up to 100 mm
Type of drive
Combustion engine
Production capacity
up to 6 m3/h of finished wood chips;
Engine power
18 HP
Rotation speed
1000 rpm
Additional features
Warranty
12 months
Dimensions
Length
1621 mm
Width
1117 mm
Height
1715 mm
Weight
300 kg
Key features
Product type
Wood shredder / Chipper
Usage
for shredding tree branches, wood waste, sawing blades with a maximum diameter of up to 100 mm
Type of drive
Combustion engine
Production capacity
up to 6 m3/h of finished wood chips;
Engine power
18 HP
Rotation speed
1000 rpm
Additional features
Warranty
12 months
